Philippines Atimonan Project
This working site is slope protection, located in Manila, Philippines. According to the actual conditions o...
Production capacity :19~22 m³/h
Concrete outlet pressure:6Mpa
Conveying distance: Horizontal 100m/Vertical 60m
Maximum aggregate diameter: 40mm
Stable
The whole vehicle has stable performance, few wearing parts, and low maintenance and use cost.PLC Control
The electrical appliances adopt PLC centralized control, which is reliable in work, long in life, and easy to program and operate.Special machine hopper
Use mold to press the hopper, not easy to accumulate material, good material absorption.Basic performance | Parameters |
Main power | 42KW(engine) |
Production capacity | 19~22 m³/h |
Cylinder diameter | 200mm |
Maximum aggregate diameter | 40mm |
Conveying distance | Horizontal 100m/Vertical 60m |
Hydraulic tank volume | 142L |
Machine weight | 2450kg |
Concrete outlet pressure | 6Mpa |
Main system pressure | 20Mpa |
Concrete distribution valve | S-pipe valve |
Hopper volume | 0.6m³ |
Feeding height | 1400mm |
Slump of concrete | 140-220mm |
Dimensions | 3400×1700×1100mm |
